不同的用途与简洁/Brief Introduction：

该线由直线方程式挤出机螺杆洗瓶烘干机箱内置式机、内服液装罐轧盖机二台手机单机版构成，分为洗涤、干躁高压蒸汽灭菌方法和装罐塑封这几个运转区，长线可联动性研发，也可手机单机版操作。可完全淋水、超音波波洗涤、冲水、冲气、烘干机箱高压蒸汽灭菌方法、冷却塔、装罐、理盖、戴盖、轧盖等步骤。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

基本特征/Characteristic：

用到超音波波擦洗及气水循环交替冲刷、远红外高温度过滤除菌、双头包装与粘口等技术设备。整线互通自功调整。运营轻松非常方便，控制了汽车电器分立式化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

高技术性能指标/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
不适用规格参数 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(中仅正常的工做36Kw)(including normal working 36 kw)
机气重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
